Denon AVR-X5200W Service Manual

P.AMP SMPS
P.AMP SMPS PCB ASS'
Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied.
※The
p
arts listed
b
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
SEMICONDUCTORS GROUP
D0101,0102 00D2760794900 KDS160-RTK/P 00D2760794900 18
D0105 00D2760794900 KDS160-RTK/P 00D2760794900 9
D0110 00D2760794900 KDS160-RTK/P 00D2760794900 9
D3903 00D2760750902 RB521S-30TE61 +REF 00D2760750902 1
D3904,3905 00D2760683998 UDZS16B-TE17 +C 00D2760683998 2
D3906,3907 251310004507S CG0603MLC-12LE 251310004507S 2
D3908 00D2760750902 RB521S-30TE61 +REF 00D2760750902 1
D3909 00D2760794900 KDS160-RTK/P 00D2760794900 1
D3912,3913 00D2760750902 RB521S-30TE61 +REF 00D2760750902 2
D6501,6502 20305003950AS 1N4007-T(DIODES) 20305003950AS 2
D6503 203010001007S D3SB60 203010001007S 1
D6507 00D2760683901 UDZS5.6B-TE17 +C E3 00D2760683901 1
D6509 20305002730AS 1N4003(HOMI) 20305002730AS 1
D6510 20205010250AS UDZSTE-1730B 20205010250AS 1 *
D6511 20205004900AS ZENER DIODE 39V_ZJ39B 1/2W 20205004900AS 1
D6512 20205004710AS P6KE150A(PANJIT) 20205004710AS 1
D6513 20305003950AS 1N4007-T(DIODES) 20305003950AS 1
D6514 20305002730AS 1N4003(HOMI) 20305002730AS 1
D6515 20305004200AS KCQ60A06 20305004200AS 1 *
D6517 00D2760794900 KDS160-RTK/P 00D2760794900 1
D6520 20205010130AS P6KE6.8A(PANJIT) 20205010130AS 1 *
D6522 20305003950AS 1N4007-T(DIODES) 20305003950AS 1
D6524 23181020150AS KIA2431AS-RTK/P 23181020150AS 1 *
D6525 20205004900AS ZENER DIODE 39V_ZJ39B 1/2W 20205004900AS 1
D6526 20305002730AS 1N4003(HOMI) 20305002730AS 1
Q0101 21785000550AS HN4A06J 21785000550AS 9
Q0102 00D2730479909 2N5551S-RTK/P 00D2730479909 9
Q0103 00D2710318909 2N5401S-RTK/P 00D2710318909 9
Q0104 00D2730479909 2N5551S-RTK/P 00D2730479909 9
Q0105 00D2710318909 2N5401S-RTK/P 00D2710318909 9
Q0106 00D2730479909 2N5551S-RTK/P 00D2730479909 9
Q0107 00D2710318909 2N5401S-RTK/P 00D2710318909 9
Q0110 00D2710318909 2N5401S-RTK/P 00D2710318909 9
Q0111 00D2730479909 2N5551S-RTK/P 00D2730479909 9
Q0112 00D2710318909 2N5401S-RTK/P 00D2710318909 9
Q0113 00D2730479909 2N5551S-RTK/P 00D2730479909 9
Q3901,3902 00D2710260905 2SA1036KT146(S/R) +C 00D2710260905 2
Q3903,3904 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 2
Q3905 00D2730464901 KTC3875S-GR-RTK/P 00D2730464901 1
Q3906 00D2690184907 KRA102S-RTK/P (10K-10K) 00D2690184907 1
Q6501 22985001450AS RK7002B 22985001450AS 1 *
Q6502 00D2730476902 KTC3876S-Y-RTK +2125 00D2730476902 1
U3901 236810090504S ILX3232D 236810090504S 1
U3902 23281004150AS NJM8080G 23281004150AS 1
U3903,3904 262010006704S JSR1165 262010006704S 2
U3905 23381001150AS SN74AHCU04D 23381001150AS 1 *
! U6501,6502 00D2623047008 PC123Y22 00D2623047008 2
! U6503 23901012400AS TOP267EG 23901012400AS 1 *
RESISTOR GROUP
R0102 nsp RD14B2E152JT(5) 00D2412398997 9
R0103 nsp RD14B2E333JT(5) 00D2412402919 9
R0104 nsp RM73B--471JT +1608 00D2472006960
9
R0105 nsp
RM73B--152JT +1608 00D2472007985 9
R0106,0107 nsp RM73B--471JT +1608 00D2472006960 18
R0108 nsp RD14B2E122JT(5) 00D2412398971 9
R0109 nsp RD14B2E333JT(5) 00D2412402919 9
R0110 00MGG0547116X 470 OHM +- 5% 1/6W 00MGG0547116X 9
R0111 00MGG0522116X 220 OHM +- 5% 1/6W 00MGG0522116X 9
R0112 nsp RD14B2E473JT(5) 00D2412402951 9
R0114 00MGG0547116X 470 OHM +- 5% 1/6W 00MGG0547116X 9
R0118,0119 00MGG0547016X 47 OHM +- 5% 1/6W 00MGG0547016X 18
R0120 nsp RM73B--334JT +2125 00D2470013942 9
R0121 nsp RM73B--473JT +1608 00D2472011942 9
R0122-0125 00D2442671956 RS14B3DR47JNBST(S) 00D2442671956 36
R0126-0128 nsp RM73B--103JT +1608 00D2472009983 27
R0129 nsp RM73B--104JT +2125 00D2470012927 9
R0130 nsp RM73B--562JT +1608 00D2472009925 9
R0131 nsp RM73B--103JT +1608 00D2472009983 9
R0132 nsp RM73B--223JT +1608 00D2472010969 9
R0133 nsp RM73B--333JT +1608 00D2472011900 9
R0134 nsp RD14B2E100JT(5) 00D2412393989 9
R0135 00D2442671901 RS14B3D100JNBST(S) 00D2442671901 9
R0136 00MGG0547116X 470 OHM +- 5% 1/6W 00MGG0547116X 9
R0137 00MGG0522116X 220 OHM +- 5% 1/6W 00MGG0522116X 9
R3902,3903 nsp RM73B--0R0KT +1608 00D2472018903 2
R3904,3905 nsp RM73B--391JT +1608 00D2472006944 2
R3906,3907 nsp RM73B--683JT +1608 00D2472011984 2
R3908,3909 nsp RM73B--154JT +1608 00D2472012967 2
R3910,3911 nsp RM73B--472JT (1608) +1608 00D2472009909 2
R3912,3913 nsp RM73B--271JT +1608 00D2472006915 2
R3914-3916 nsp RM73B--102JT +1608 00D2472007943 3
R3917,3918 nsp RM73B--470JT +1608 00D2472004920 2
R3919 nsp RM73B--332JT +1608 00D2472008968 1
R3920 nsp RM73B--222JT +1608 00D2472008926 1
R3921 nsp RM73B--104JT +1608 00D2472012925 1
R3922,3923 nsp RM73B--154JT +1608 00D2472012967 2
R3924,3925 nsp RM73B--123JT +1608 00D2472010901 2
R3926,3927 nsp RM73B--470JT +1608 00D2472004920 2
R3928,3929 nsp RM73B--102JT +1608 00D2472007943 2
R3930,3931 nsp RM73B--474JT +1608 00D2472013982 2
R3932 nsp RM73B--330JT +1608 00D2472003989 1
R3933,3934 nsp RM73B--750JT +1608 00D2472004975 2
R3937,3938 nsp RM73B--330JT +1608 00D2472003989 2
R3939,3940 nsp RM73B--471JT +1608 00D2472006960 2
R3945,3946 nsp RM73B--473JT +1608 00D2472011942 2
R3947,3948 nsp RM73B--334JT +1608 00D2472013940 2
R3951,3952 nsp RM73B--330JT +1608 00D2472003989 2
R6501-6503 nsp RD14B2E225JT(5) 00D2412405990 3
4

Denon AVR-X5200W Specifications

General

Receiver type	Surround
Frequency range	20 - 20000 Hz
Output impedance	16 Ω
Speaker selector	A+B
Pre-out connectivity	Yes
Audio output channels	- channels
Power output per channel (1KHz@6 Ohm)	205 W
Power output per channel (20-20KHz@8 Ohm)	140 W
HDMI in	8
Remote (IR) input	1
Composite video in	5
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Connectivity technology	Wired & Wireless
Speakers connectivity type	-
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Supported radio bands	AM, FM
Internet radio services supported	Spotify, vTuner
Optical drive included	No
Product color	Silver
Audio decoders	Dolby TrueHD, DTS 96/24, DTS Neo:X, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	730 W

Weight and Dimensions

Depth	393 mm
Width	434 mm
Height	167 mm
Weight	14200 g
