Denon AVR-X5200W Service Manual

P.AMP SMPS
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
R6504-6506 nsp RD14B2E105JT(5) 00D2412405974 3
R6507 nsp RD14B2E334JT(5) 00D2412404959 1
R6508 nsp RM73B--105JT +1608 00D2472014965 1
R6509 nsp RM73B--392JT +1608 E3 00D2472008984 1
R6509 nsp RM73B--622JT +1608 E2,E1C 00D2472009938 1
R6510 nsp RM73B--822JT +1608 00D2472009967 1
R6511,6512 nsp RD14B2E225JT(5) E3 00D2412405990 2
R6514 nsp RM73B--563JT +1608 00D2472011968 1
R6515 00D2442051961 RS14B3A101JNBST(S) 00D2442051961 1
R6516 nsp RD14B2E6R8JT(5) 00D2412393947 1
R6517 nsp RM73B--560JT +1608 00D2472004946 1
R6519 nsp RM73B--103JT +1608 00D2472009983 1
R6520 nsp RM73B--152JT +1608 00D2472007985 1
R6521 00D2442050904 RS14B3A220JNBST(S) 00D2442050904 1
R6522 nsp RM73B--560JT +1608 00D2472004946 1
R6523 nsp RM73B--682JT +1608 00D2472009941 1
R6524 nsp RM73B--562JT +1608 00D2472009925 1
R6525 nsp RM73B--223DT(1608) 00D2472036927 1
R6526 nsp RM73B--105JT +1608 00D2472014965 1
R6527 nsp RM73B--682DT(1608) 00D2472041967 1
R6528 nsp RM73B--470JT +1608 00D2472004920 1
R6532 nsp RM73B--0R0KT +1608 00D2472018903 1
R6533 00D2442051974 RS14B3A102JNBST(S) 00D2442051974 1
R6536 nsp RM73B--682JT +1608 00D2472009941 1
R6537 nsp RM73B--0R0KT +1608 00D2472018903 1
CAPACIITORS GROUP
C0101 00D2544583971 CE04W1H470MT(ROB) 00D2544583971 9
C0102 133050086527S CQ93M2A102JT(PEF) 133050086527S 9
C0103 133050086565S CQ93M2A222JT(PEF) 133050086565S 9
C0104 nsp CC73CH1H101JT +1608 00D2570506951 9
C0105 13405012940AS CE04W1C101MT(KR3) 13405012940AS 9
C0106 13405013340AS CE04W1E471MT(KR3) 13405013340AS 9
C0107 nsp CC73CH1H101JT +1608 00D2570506951 9
C0109 133050086503S CQ93M2A221JT(PEF) 133050086503S 9
C0110 13405013340AS CE04W1E471MT(KR3) 13405013340AS 9
C0111 nsp C1608X7R1H104K 00MDK9610430Y 9
C0113 nsp C1608X7R1H104K 00MDK9610430Y 9
C0114,0115 13405018640AS CE04W2A010MT(KR3) 13405018640AS 18
C0116 133050083504S CQ93M2A473JT(PEF) 133050083504S 9
C0121,0122 13405018640AS CE04W2A010MT(KR3) 13405018640AS 18
C3901 nsp CC73CH1H102JT +1608 00D2570508988 1
C3904,3905 nsp CK73B1H102KT +1608 00D2570509929 2
C3906 nsp CK73B1E104KT +1608 00D2570516954 1
C3907,3908 nsp CC73CH1H221JT +1608 00D2570507934 2
C3909-3911 nsp CK73B1H102KT +1608 00D2570509929 3
C3912,3913 nsp CK73B1E104KT +1608 00D2570516954 2
C3914,3915 13405014840AS CE04W1J100MT(KR3) 13405014840AS 2
C3916,3917 nsp CC73CH1H330JT +1608 00D2570504940 2
C3918 nsp CK73B1H102KT +1608 00D2570509929 1
C3919,3920 13405012440AS CE04W0J221MT(KR3) 13405012440AS 2
C3921,3922 nsp CC73CH1H101JT +1608 00D2570506951 2
C3923,3924 nsp CK73B1E223KT +1608 00D2570516909 2
C3925,3926 nsp CK73B1H682KT +1608 00D2570510950 2
C3927,3928 13405014840AS CE04W1J100MT(KR3) 13405014840AS 2
C3929 nsp CK73B0J475KT +1608
00D2570522906 1
C3930
nsp
CK73B1E104KT +1608 00D2570516954 1
C3931,3932 13405013240AS CE04W1E470MT(KR3) 13405013240AS 2
C3933-3939 nsp CK73B1E104KT +1608 00D2570516954 7
C3940,3941 nsp CK73B1H102KT +1608 00D2570509929 2
C3942,3943 nsp CK73B1H103KT (1608) +1608 00D2570501901 2
C3944 nsp CK73B1E104KT +1608 00D2570516954 1
C3945 nsp CK73B1H102KT +1608 00D2570509929 1
C5801-5804 nsp CK73B0J475KT +1608 00D2570522906 4
! C6501,6502 00D2538032700 CK452EAC102MC
(
KX
)
00D2538032700 2
! C6503 00D2538022707 CK45F2EAC103MC 00D2538022707 1
! C6504,6505 13305016720AS MPXLC104K2751
5
13305016720AS 2 *
C6506 13405028320AS CE04W2G151MC(CXW) 13405028320AS 1 *
C6509 nsp CK73B1E473KT +1608 E2,E1C 00D2570516941 1
C6510 nsp CK73B1E104KT +1608 00D2570516954 1
! C6511,6512 00D2538022707 CK45F2EAC103MC 00D2538022707 2
C6515 13405040350AS CE04W1E470MT(KZH) 13405040350AS 1 *
C6516 nsp C1608X7R1H104K 00MDK9610430Y 1
C6517 13305015021AS CQ93M3A272J(PHF) 13305015021AS 1 *
C6519 13405040450AS CE04W1H220MT(KZH) 13405040450AS 1 *
! C6520 00D2538029726 CK45F2EAC332MC
(
KX
)
00D2538029726 1
C6524 nsp CK73B0J475KT +1608 00D2570522906 1
C6525-6527 13405028420AS CE04W0J392MC(ZL) 13405028420AS 3 *
C6528 nsp CK73B0J475KT +1608 00D2570522906 1
C6529 nsp CK73B1E104KT +1608 00D2570516954 1
C6530 nsp CK73B0J475KT +1608 00D2570522906 1
C6532 133050086565S CQ93M2A222JT(PEF) 133050086565S 1
OTHER PARTS GROUP
B5801 nsp M3 SCREW TERMINAL 00D2051034010 1
B6501 nsp M3 SCREW TERMINAL(CMD1A834) 44431033900AS 1 *
B6503 nsp M3 SCREW TERMINAL(CMD1A834) 44431033900AS 1 *
! F0050 652010025063S L=20mm 250V/T8
A
E3 652010025063S 1
! F0050 00D2061091014 FUSE
(
ET5A
)
E2 00D2061091014 1 2
! F0050 0520100170060 # T5A L 250V 0218005.MX
P
E1C 0520100170060 1 2
! F0070 65205003443AS FUSE
(
SCT2A
)
65205003443AS 1 *
H0061,0062 nsp FUSE CLIP(TAPE) 00D2020040909 2
K3901 64301000710AS 2PIN PIN JACK(RCA-206BG-00-05)-AU-RD/WH 64301000710AS 1
K3902,3903 643010086019S MINI JACK(PJ-308-02(RD)) 643010086019S 2
K3904,3905 643010086002S MINI JACK(PJ-308-02) 643010086002S 2
K3906 646010018015S 2P PIN JACK(MSD-252V-31)-AU-O 646010018015S 1
L0101 00D2350191007 INDUCTOR(1MH) 00D2350191007 9
L3903 nsp E.FIL(BLM21PG221SN1)+2125 00D2350147909 1
! L6501 11101005000AS L.FILTER-12290
(
SQE24x24
)
E3 11101005000AS 1 *
! L6501 11101010120AS L.FILTER-07650
(
SQE24x24
)
E2,E1C 11101010120AS 1 *
N0101 nsp 13P SOCKET(C125Z2) 645010057017S 9
N0102 nsp S5B-EH 00MYP06003950 9
N3901 64301017200AS 9P D-SUB CONNECTOR(D227FD009S100BY) 64301017200AS 1
N3902 nsp 7P SOCKET(C125Z2) 645010068000S 1
N3903 nsp 19P FFC BASE (P=1) 00D2050892020 1
N5801-5809 nsp 13P PLUG(C125Z1) 645010056014S 9
N5813 nsp S11B-PH-K-S (LF)(SN) 00MYJ06006510 1
N5814 nsp S3B-PH-K-S (LF)(SN) 00MYJ06006430 1
5

Denon AVR-X5200W Specifications

General

Receiver type	Surround
Frequency range	20 - 20000 Hz
Output impedance	16 Ω
Speaker selector	A+B
Pre-out connectivity	Yes
Audio output channels	- channels
Power output per channel (1KHz@6 Ohm)	205 W
Power output per channel (20-20KHz@8 Ohm)	140 W
HDMI in	8
Remote (IR) input	1
Composite video in	5
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Connectivity technology	Wired & Wireless
Speakers connectivity type	-
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Supported radio bands	AM, FM
Internet radio services supported	Spotify, vTuner
Optical drive included	No
Product color	Silver
Audio decoders	Dolby TrueHD, DTS 96/24, DTS Neo:X, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	730 W

Weight and Dimensions

Depth	393 mm
Width	434 mm
Height	167 mm
Weight	14200 g
