Denon AVR-X5200W Service Manual

3.5. DIAGNOSTIC MODE (Service Path Check Mode)
3.5.1. Actions
This function is convenient for conrming problem paths in the product and executing a path check after repair.
The Video and Audio paths can be checked.
The backup data is not rewritten.
3.5.2. Starting up
Hold down buttons "STATUS" and "ZONE3 SOURCE" at the same time and press the power button to turn on the power.
Select "1. SERVICE CHECK" and press the "ENTER" button to start the diagnostic mode.
The "TUNED", "STERO" and "RDS" segments are lit in this mode.
3.5.3. Canceling diagnostic mode
Press the power button to turn off the power.
3.5.4. Selecting items
Press
q
button to switch between video items and audio items.
Press button
w
or
e
to select the previous or next item.
The unit Remote control unit
Actions
q w e q w e
Audio ⇔ Video PREVIOUS NEXT Audio ⇔ Video PREVIOUS NEXT
Button DIMMER CURSOR
0
CURSOR
1
SLEEP CURSOR
0
CURSOR
1
3.5.5. Audio system conrmation items
g. XX: See the block diagram of the g.XXth.
Paths conrmation item Display Settings Contents of conrmation Remarks
1
Analog
(MAIN ZONE)
A 0 1 : A N A L O G P A S S
Input Source : CBL/SAT
Input Mode : Analog(xed)
Sound mode : Direct
Vol. : 60.0（-20.0dB）
Amp assign : 9.1ch
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Front L/R)
・Analog input ⇒ Preout output (Front L/R)
(
b
As the input source, you can switch from CBL/SAT to other ones.）
2
Digital
(MAIN ZONE)
A 0 2 : D I G I T A L
Input Source : CBL/SAT
Input Mode : Digital(xed)
Sound mode : Multi Ch Stereo
Vol. : 60.0（-20.0dB）
Amp assign : 9.1ch
Speaker Select : Floor
Speaker Cong : All Speaker=Small/Subwoofer=2spkrs
ZONE2 : OFF
ZONE3 : OFF
・Digital input ⇒ Speaker output (Front L/R, Center, Surround L/R, Surround Back L/R)
・Digital input ⇒ Preout output (Front L/R, Center, Subwoofer1/2, Surround L/R, Surround Back L/R)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
3
Digital (signal) Path
(ZONE2)
A 0 3 : D I G I T A L - Z 2
Input Source : Online Music
Input Mode : Auto
Sound mode : Stereo
Amp assign : 7.1ch + ZONE2
Speaker for ZONE2 : SURROUND BACK
ZONE2 : ON
ZONE2 Source : Source
Z2 Vol. : 60.0（-20.0dB）
ZONE3 : OFF
・Digital(PCM) input ⇒ Speaker output (Surround Back L/R → ZONE2 L/R)
・Digital(PCM) input ⇒ Preout output (ZONE2 L/R)
(
b
As the input source, you can switch from Online Music to other ones.)
4
Digital (signal) Path
(ZONE3)
A 0 4 : D I G I T A L - Z 3
Input Source : Online Music
Input Mode : Auto
Sound mode : Stereo
Amp assign : 7.1ch + ZONE3
Speaker for ZONE3 : FRONT WIDE/HEIGHT 2
ZONE2 : OFF
ZONE3 : ON
ZONE3 Source : Source
Z3 Vol. : 60.0（-20.0dB）
・Digital(PCM) input ⇒ Speaker output (Front Wide/Height2 L/R → ZONE3 L/R)
・Digital(PCM) input ⇒ Preout output (ZONE3 L/R)
(
b
As the input source, you can switch from Online Music to other ones.)
5
HDMI
(MAIN ZONE)
A 0 5 : H D M I
Input Source : CBL/SAT
Input Mode : HDMI(xed)
Sound mode : Stereo
Vol. : 60.0（-20.0dB）
Amp assign : 9.1ch
ZONE2 : OFF
ZONE3 : OFF
・HDMI Input ⇒ Speaker output (Front L/R)
・HDMI Input ⇒ Preout output (Front L/R)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
g.01
g.02a
g.02b
g.03a
g.03b
g.03c
g.04a
g.04b
g.05a
g.05b
g.05c
27

Denon AVR-X5200W Specifications

General

Receiver type	Surround
Frequency range	20 - 20000 Hz
Output impedance	16 Ω
Speaker selector	A+B
Pre-out connectivity	Yes
Audio output channels	- channels
Power output per channel (1KHz@6 Ohm)	205 W
Power output per channel (20-20KHz@8 Ohm)	140 W
HDMI in	8
Remote (IR) input	1
Composite video in	5
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Connectivity technology	Wired & Wireless
Speakers connectivity type	-
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Supported radio bands	AM, FM
Internet radio services supported	Spotify, vTuner
Optical drive included	No
Product color	Silver
Audio decoders	Dolby TrueHD, DTS 96/24, DTS Neo:X, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	730 W

Weight and Dimensions

Depth	393 mm
Width	434 mm
Height	167 mm
Weight	14200 g
