Denon AVR-X5200W Service Manual

Paths conrmation item Display Settings Contents of conrmation Remarks
6
A/D
(MAIN ZONE)
A 0 6 : A D
Input Source : CBL/SAT
Input Mode : Analog(xed)
Sound mode : Multi Ch Stereo
Vol. : 60.0（-20.0dB）
Amp assign : 9.1ch
Height Speakers=2 Height Speakers
Height Layout=Front Height
Speaker Select : Floor
Speaker Cong : All Speaker=Small/Subwoofer=2spkrs
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Front L/R, Center, Surround L/R, Surround Back L/R, Front Wide L/R)
・ Analog input ⇒ Preout output, SW(20Hz) (Front L/R, Center, Subwoofer1/2, Surround L/R, Surround Back L/R, Front
Wide L/R)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
7
Amp Assign
(ZONE2)
A 0 7 : A S S I G N - Z 2
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Stereo
Amp assign : 7.1ch + ZONE2
Speaker for ZONE2 : Surround Back
ZONE2 : ON
Z2 Source : Source
Z2 Vol : 60（-20dB)
ZONE3 : OFF
・Analog input ⇒ Speaker output (Surround Back L/R → ZONE2 L/R)
・Analog input ⇒ Preout output (ZONE2 L/R)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
8
Amp Assign
(ZONE3)
A 0 8 : A S S I G N - Z 3
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Stereo
Amp assign : 7.1ch + ZONE3
Speaker for ZONE3 : FRONT WIDE/HEIGHT 2
ZONE2 : OFF
ZONE3 : ON
ZONE3 Source : Source
Z3 Vol. : 60.0（-20.0dB）
・Analog input ⇒ Speaker output (Front Wide/Height2 L/R → ZONE3 L/R)
・Analog input ⇒ Preout output (ZONE3 L/R)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
9
Amp Assign
（ZONE2/ZONE3-MONO）
A 0 9 : A S S I G N - Z 3 / 3 M
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : STEREO
Amp assign : 7.1ch + ZONE2/3-MONO
Speaker for ZONE2/3 : HEIGHT1
ZONE2 : ON
Z2 Source : Source
Z2 Vol : 60（-20dB）
ZONE3 : ON
Z3 Source : Source
Z3 Vol : 60（-20dB）
・Analog input ⇒ Speaker output (Height1 L → ZONE2 MONO, Height2 R → ZONE3 MONO)
・Analog input ⇒ Preout output (ZONE2 L/R → ZONE2 MONO, ZONE3 L/R → ZONE3 MONO)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
10
Amp Assign
(7.1ch (Bi-Amp)
A 1 1 : A S S I G N - B i A M P
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Multi Ch Stereo
Vol. : 60.0（-20.0dB）
Amp assign : 7.1ch (Bi-Amp)
Speaker for Bi-Amp : SURROUND BACK
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Surround Back L/R → Front L/R）
(
b
As the input source, you can switch from CBL/SAT to other ones.)
11
Front Height
A 1 4 : F R O N T H E I G H T
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Multi Ch Stereo
Vol. : 60.0（-20.0dB）
Amp assign : 11.1ch
Height Speakers : 4Height Speakers
Height Layout : Top Front & Top Rear
Pre-out Channel : Top Rear
Speaker Cong : Front Wide=None
Speaker Select : Floor & Height
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Height 1 L/R → Top Front L/R）
・Analog input ⇒ Preout output (Height 1 L/R → Top Front, Height 2 L/R → Top Rear)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
12
Front Wide
A 1 5 : F R O N T W I D E
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Multi Ch Stereo
Vol. : 60.0（-20.0dB）
Amp assign : 11.1ch
Height Spakers : 4 Height Speakers
Height Layout : Front Height & Top Middle
Wide/Height2 : Front Wide
Speaker Cong: S.Back=None
Speaker Select : Floor
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Front Wide L/R）
・Analog input ⇒ Preout output (Front Wide L/R）
(
b
As the input source, you can switch from CBL/SAT to other ones.)
g.06a
g.06b
g.07
g.08
g.09
g.10a
g.10b
g.11a
g.11b
g.12a
g.12b
28

Denon AVR-X5200W Specifications

General

Receiver type	Surround
Frequency range	20 - 20000 Hz
Output impedance	16 Ω
Speaker selector	A+B
Pre-out connectivity	Yes
Audio output channels	- channels
Power output per channel (1KHz@6 Ohm)	205 W
Power output per channel (20-20KHz@8 Ohm)	140 W
HDMI in	8
Remote (IR) input	1
Composite video in	5
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Connectivity technology	Wired & Wireless
Speakers connectivity type	-
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Supported radio bands	AM, FM
Internet radio services supported	Spotify, vTuner
Optical drive included	No
Product color	Silver
Audio decoders	Dolby TrueHD, DTS 96/24, DTS Neo:X, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	730 W

Weight and Dimensions

Depth	393 mm
Width	434 mm
Height	167 mm
Weight	14200 g
