Denon AVR-X5200W Service Manual

Paths conrmation item Display Settings Contents of conrmation Remarks
13
Front Amp>>Height 1
A 2 0 : F - A M P H E I G H T
Input Source : CBL/SAT
Input Mode:Auto
Sound mode: Multi ch Stereo
Vol. : 60.0（-20.0dB）
Amp assign : 11.1ch
Height Speakers=4Height Speakers
Height Layout=Top Front & Top Rear
Pre-out Channel=Front & Top Rear
Speaker Conog : Surround Back=None
Speaker Select=Floor & Height
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Height1 L/R → Top Front L/R）
・Analog input ⇒ Preout output (Height1 L/R → Top Front, Height2 → Top Rear L/R）
(
b
As the input source, you can switch from CBL/SAT to other ones.)
14
Front Amp>>Front Wide
A 2 1 : F - A M P W I D E
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Multi ch Stereo
Vol. : 60.0（-20.0dB）
Amp assign : 11.1ch
Height Speakers : 2Height Speakers
Height Layout : Front Height
Pre-out Channel : Front
Speaker Select=Front
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Front Wide L/R)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
15
Wide/Height Amp>>Surround Back
A 2 3 : H - A M P B A C K
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Multi ch Stereo
Vol. : 60.0（-20.0dB）
Amp assign : 7.1ch+ZONE2
Speakers for ZONE2 : FRONT WIDE/HEIGHT 2
Height Layout : Front Height
Speaker Select : Floor
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Surround Back L/R)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
g.13a
g.13b
g.14a
g.14b
g.15s
g.15b
29

Denon AVR-X5200W Specifications

General

Receiver type	Surround
Frequency range	20 - 20000 Hz
Output impedance	16 Ω
Speaker selector	A+B
Pre-out connectivity	Yes
Audio output channels	- channels
Power output per channel (1KHz@6 Ohm)	205 W
Power output per channel (20-20KHz@8 Ohm)	140 W
HDMI in	8
Remote (IR) input	1
Composite video in	5
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Connectivity technology	Wired & Wireless
Speakers connectivity type	-
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Supported radio bands	AM, FM
Internet radio services supported	Spotify, vTuner
Optical drive included	No
Product color	Silver
Audio decoders	Dolby TrueHD, DTS 96/24, DTS Neo:X, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	730 W

Weight and Dimensions

Depth	393 mm
Width	434 mm
Height	167 mm
Weight	14200 g
