57 EXADR174 I/O EXT ADR17 External memory address 17
58 EXADT7 I/O EXT ADR7 External memory address 7 / data 12
59 EXADT6 I/O EXT ADR6 External memory address 6 / data 5
60 EXADT5 I/O EXT ADR5 External memory address 5 / data 13
61 EXADT4 I/O EXT ADR4 External memory address 4 / data 6
62 EXADT3 I/O EXT ADR3 External memory address 3 / data 14
63 EXADT2 I/O EXT ADR2 External memory address 2 / data 7
64 EXADT1 I/O EXT ADR1 External memory address 1 / data 15
65 P0 I/O EXT ADR20 External memory address 20
66 P1 I/O SDA Serial 0 output data
67 P2 I/O SCL Serial 0 clock
68 VSS - GND GND
69 VDD33 - 3.3V I/O supply
70 P3 I/O SYSRXD Serial 1 input data
71 P4 I/O SYSTXD Serial 1 output data
72 P5 I/O REMO/INTST External interrupt 2
73 P6 I/O V-CS Serial 2 input data
74 P7 I/O V-DATA Serial 2 output data
75 P8 I/O V-CLK Serial 2 clock
76 P9 I/O MSDATAI Serial 3 input data
77 P10 I/O MSDATAO Serial 3 output data
78 P11 I/O MSCLK Serial 3 clock
79 P12 I/O CS1 Extension chip select
80 P13 I/O SACD-READY Serial 3 data receipt flag
81 P14 I/O MSLAT Serial 3 data transmit flag
82 VSS - GND GND
83 VDD12 - 1.2V Logic supply
84 NRST I RESET Master reset
85 FG I/O FG-IN System ucom port 21
86 DRV5 I/O CD/DVD System ucom port 15
87 DRV4 I/O IN_SW System ucom port 16
88 DRV3 I/O HFM_ON/OFF System ucom port 17
89 DRV2 I/O TRY_DRV System ucom port 18
90 DRV1 I/O SP_DRV System ucom port 19
91 DRVO I/O SL_DRV System ucom port 20
92 VSS - GND GND
93 VDD33 - 3.3V I/O supply
94 MONl7 I/O PSP-MCK/MONI7 System ucom port 22
95 MONl6 I/O PSP-WAD7/MONI6 System ucom port 23
96 MONl5 I/O PSP-WAD6/MONI5 System ucom port 24
97 MONl4 I/O PSP-WAD5/MONI4 System ucom port 25
98 MONl3 I/O PSP-WAD4/MONI3 System ucom port 26
99 MONl2 I/O PSP-WAD3/MONI2 System ucom port 27
100 MONl1 I/O PSP-WAD2/MONI1 System ucom port 28
101 MONlO I/O PSP-WAD1/MONI0 System ucom port 29
102 AVDDD - 3.3V Analog supply
103 PLF1L1 O PLFIL1 External filter for DRC-VCO
104 AVSSD - GND Analog GND
105 VREFH7 O V-REF-H7 ADC reference voltage for DRC (TOP)
106 VREFL7 O V-REF-L7 ADC reference voltage for DRC (BTM)
107 CCAPA O CCAPA Inline filter for CAPA block
108 AVSSC - GND Analog GND
109 CDATA O CDATA Inline filter for DATA block
110 AVDDG - 3.3V Analog supply
111 ANAMONl1 O TP_ANAMONI1 Internal analog monitor 1
112 ANAMONI2 O TP_ANAMONI2 Internal analog monitor 2
113 RFINN I RFINN External RF input (-)
114 RFINP I RFINP External RF input (+)
115 VINIRF I VIN1RF RF input 1
116 VIN2RF I VIN2RF RF input 2
117 VIN4RF I VIN4RF RF input 4
118 VIN3RF I VIN3RF RF input 3
119 AVDDB - 3.3V Analog supply
120 VREFH5 I V-REF-H5 5 bit AD reference Voltage "H"
121 VREFL5 I V-REF-L5 5 bit AD reference Voltage "L"
122 AVSSB - GND Analog GND
123 LPC1 I LPC1 DVD LPC input
Pin No. Pin Name Type Symbol Function
