37
DCD-CX3
124 LPCO1 O LPCO1 DVD LPC output
125 LPC2 I LPC2 CD LPC input
126 LPCO2 O LPCO2 CD LPC output
127 VREFH O V-REFH Reference Voltage 2.20V output
128 VHALF O V-HALF Reference Voltage 1.65V output
129 VIN10 I VIN10 CD head input
130 VIN9 I VIN9 CD head input
131 VIN5 I VIN5 CD head input
132 VIN6 I VIN6 CD head input
133 VIN7 I VIN7 DVD head input
134 VIN8 I VIN8 DVD head input
135 VIN3 I VIN3 DVD head input
136 VIN4 I VIN4 DVD head input
137 VIN2 I VIN2 DVD head input
138 VIN1 I VIN1 DVD head input
139 ADO I KEY0 Servo AD input 0
140 AD1 I KEY1 Servo AD input 1
141 AD2 I IOP_CHECK(CD/DVD) Servo AD input 2
142 AD4 I REG Servo AD input 4
143 AVSSH - GND Analog GND
144 PWM1 O TR_DRV Tracking drive output
145 PWMO O FO_DRV Focus drive output
146 AVDDH - 3.3V Analog supply
147 DAC3OUT O OPEN Cr/R analog video output
148 DAC2OUT O OPEN Cb/B analog video output
149 DAC1OUT O OPEN Y/G analog video output
150 AVDDF - 3.3V Analog supply for VDAC
151 COMP1 I COMP1 Compensation pin for DAC1
152 VREF I VREF Reference Voltage for DAC
153 IREF1 I IREF1 Bias current adjust pin for DAC
154 COMP2 I COMP2 Compensation pin for DAC2
155 AVSSF - GND Analog GND for VDAC
156 DAC4OUT O OPEN Y/Comp analog video output
157 DAC5OUT O OPEN C analog video output
158 AVDDE - 3.3V Analog supply for PLL
159 AVSSE - GND Analog GND for PLL
160 AVDDG - 3.3V Analog supply for PLL
161 AVSSG - GND Analog GND for PLL
162 OSCl I OSC-IN Oscillator input (27MHz)
163 OSCO O OSC-OUT Oscillator output (27MHz)
164 VSS - GND GND
165 VDD12 - 1.2V Logic supply
166 DACCK I/O MCK/SD7 Stream data output 7
167 LRCK O LRCK/SD6 Stream data output 6
168 SRCK O BCK/SD5 Stream data output 5
169 ADOUT3 O MIXLR/SD4 Stream data output 4
170 ADOUT2 I/O DATA2/SD3 Stream data output 3
171 ADOUT1 I/O DATA1/SD2 Stream data output 2
172 ADOUTO I/O DATA0/SD1 Stream data output 1
173 IECOUT O SPDIF/SD0 Stream data output 0
174 VSS - GND GND
175 VDD33 - 3.3V I/O supply
176 VDIO7 I/O DXP_CS CS for DXP6001
177 VDIO6 I/O DXP_RST RST for DXP6001
178 VDIO5 I/O DXP/DSD_DI DATA for DXP6001 and DSD1796
179 VDIO4 I/O DXP/DSD_CL CLOCK for DXP6001 and DSD1796
180 VDI03 I/O DSD_CS CS for DSD1796
181 VDIO2 I/O DSD_RST RST for DSD1796
182 VDI01 I/O SMUTE SMUTE for CXD2753
183 VDIOO I/O IO_RST RST for CXD2753
184 VDD33 - 3.3V I/O supply
185 VSS - GND GND
186 EXTRG1 I/O OPEN Video clock output
187 SCLOCK I SCLOCK Input clock for debug
188 SDATA I/O SDATA Input/output data for debug
189 EXTRGO I/O PDETECT/EXTRGO System ucom port 41
190 TRCCLK I/O CLK33M Master clock for External AVDEC
Pin No. Pin Name Type Symbol Function
