Barcode Handy Terminal
Ch
arging w h the battery charger (CH-201A and CH-704) it
1. Check the battery cartridge terminals and insert the
artridge.
commercial AC power source
(230 V AC).
The LED will turn red when charging is commenced.
lete.
c
2. Connect the power cable to the CH-201A and
connect the plug to a
3. The LED will turn OFF when charging is comp
− Point − Charging takes approximately 3
hours.
An only slightly discharged battery
cartridge should take this time to
become fully charged.
4. Slide the battery cover lock (1) in the direction
indicated by the arrow and remove the battery
cover (2).
Terminal
Red LED ON
OFF
