Current Transformers
Recommended CT Phase Shift Values
Clamp On
CT-CON-0150EZ
CT-CON-1000
1.10°
0.20°
Split Core Small
CT-SCS-0050
CT-SCS-0100
2.20°
2.20°
Split Core
Medium
CT-SCM-0100
CT-SCM-0200
CT-SCM-0400
CT-SCM-0600
1.75°
1.50°
1.30°
1.30°
Split Core Large
CT-SCL-0600
CT-SCL-1000
0.00°
0.00°
Split Core High
Accuracy
CT‐SHS‐0005
CT‐SHS‐0015
0.50°
0.50°
Hinge Mini
CT-HSC-020
CT-HSAC-050
0.75°
0.75°
Hinge MIDI
CT-HMC-0100
CT-HMC-0200
0.12°
0.30°
Revenue Grade
Toroidal Solid
Core
CT-RGT12-0005
CT-RGT12-0020
CT-RGT12-0050
CT-RGT12-0100
0.00°
0.00°
0.00°
0.00°
Revenue Grade
Split Core
CT-SRS-005
CT-SRS-050
CT-SRL-100
CT-SRL-200
CT-SRL-400
-0.10°
-0.23°
0.06°
0.06°
-0.06°
Recommended CT Phase Shift Values
