DENT Instruments
ELITEpro
Introduction
ELITEpro XC TECHNICAL SPECIFICATIONS
Specification
Description
Memory
16 MB non-volatile
Service Types
Single Phase-Two Wire, Single Phase-Three Wire, Three Phase-Four Wire (WYE),
Three Phase-Three Wire (DELTA), DC Systems (solar/battery).
Voltage Channels
3 channels, CAT III, 0-600 VAC (line-to-line) or 600 VDC
Current Channels
4 channels, .67 VAC max, +/- 1 VDC max; ideal for 333 mV full scale CTs
Maximum Current Channel
Input Voltage
External transducer dependent; 200% of current transducer rating (mV CTs);
Measure up to 6000A with RōCoil CTs
Measurement Type
True RMS using high-speed digital signal processing (DSP)
Line Frequency
DC/50/60Hz
Waveform Sampling
12 kHz
200 samples/cycle at 60Hz
240 samples/cycle at 50Hz
Channel Sampling Rate
(internal sampling)
8 Hz or every 125 mSec.
Data Interval
The default integration period is fifteen minutes. The choices are 1, 3, 10, 15, 30
seconds; 1, 2, 5, 10, 15, 20 and 30 minutes; 1 and 12 hours; 1 day.
Energy Measurements
Volts, Amps, Amp-Hrs (Ah), kW, kWh, kVAR, kVARh, kVA, kVAh, Displacement
Power Factor (dPF). All parameters for each phase and for system total.
Analog Measurements
0–10 Volts, 0 or 4–20 ma current loop non-isolated, external power for current
loop. User scaling for sensor reporting in physical units.
Accuracy
Better than 1% (<0.2% typical) for V, A, kW, kVAR, kVA, PF
Resolution
0.01 Amp, 0.1 Volt, 1 Watt, 1 VAR, 1 VA, 0.01 Power Factor, 0.001 ANALOG
LED Indicators
Tri-colors (red, green, and blue): 1 LED to indicate communication, 4 LEDs for
correct phasing (green when voltage and current on the same phase; red when
incorrectly wired, blue for wireless, Bluetooth wireless technology, and
Ethernet).
Communication
USB (Standard)
USB standard (Type B). 1.8 M (6 FT) A-to-B USB Cable (included)
ETHERNET (Standard)
Standard RJ-45 Connector supports 10/100 MB Ethernet over Cat 5 or better.
Configure for DHCP or Static IP address.
BLUETOOTH® Wireless
Technology (Optional)
Internal antenna: typical conditions <10ft up to 100ft range. Requires Bluetooth
wireless technology adapter on Window PC. Adapter must support the Serial Port
Profile (SPP).
