Main buttons and icons
Tap this icon to access the tightening results and curves.
Tap this icon to configure:
• System
• Tightening units
• Tools
• Psets
• Assembly Processes
• Feature management
Tap this icon to access the following actions.
• updating of the system firmware
• using of a CVI LOGIX program
• backup of configurations and results
• management of I/O events
• management of the system memory
• management of results, logs and user infos
• getting information on the tool
• pairing a tool via eDOCK or RFID
• displaying of the user info logs
• management of the RIM
• displaying the system firmware version
Tap this button on the front panel to display the start screen.
Tap this icon to validate.
Tap this icon to quit.
Technical data
Power supply
100-120 / 200-240 V~
50/60 Hz
Single-phase
CONNECT can alternatively be powered by 24 V DC provided by an external output.
Power consumption
Model
A
at 100-240 V~
A
at 24 V DC
CONNECT-W 1.5 4
CONNECT-X 1.5 4
