EN Operation
03/2020 33 / 84
Operation
Configuration Instructions
How to create a tightening unit
Create one tightening unit per tool.
Before starting, check that the RIM contains enough UVs for the planned configuration. If not, go to the chapter
Rebalancing UV to the RIM [Page57]
Launch CVI CONFIG.
Plug CONNECT to the computer as shown in chapter Connecting to a computer [Page21].
Create a working area and right-click it to add your CONNECT.
Type the IP address and click Update. A green tick indicates the communication is established.
Click CONNECT and right-click to add a tightening unit.
Go to Feature management.
Select the tightening unit and click Activate.
You can also activate the feature CVILOGIX if required.
Click this icon to update the product.
How to associate a tool to a tightening unit
Select the tightening unit which drives the tool.
Swipe the tile to display Easy pairing.
Pair the tool as shown in chapter Pairing tools via eDOCK [Page28] or Pairing tools via RFID [Page27].
Tap the tile Easy pairing to start the procedure.
Unplug and plug the battery pack to the tool.
