Desoutter CVI3 Vision Installation And Upgrades

6159924330 - 08/2020 - 39 -
T1
T2
T3
T4
T5
T6
T1
T2
T3
T4
T5
T6
2
1
1 Socket
2 Locking part
Select the tube, slide the locking part to block it and tighten with the knurled knob or the screw+washer provided in
the packing box.
Installing the bit module
Select a bit in the following range:
HEX: 4 to 8
TORX: 25 to 40
17.7 mm
Remove the V-shaped part.
Place the bit module and secure it by using the M5x20 screw supplied in the packing box.
Adjusting the bit module setting
