0065-0647-OM Rev E 7550 OWNER’S MANUAL
INSTALLATION, CONT.
Install the Scale on the Wall Mount
1. Remove the strap securing the weighing platform to the scale frame, and then remove the
foam inserts between the weighing platform and frame. Refer to the notes and picture in
Step 4 of the UNPACKING section.
2. With an assistant, lift the scale above the wall mount and then lower it into position in the
channel of the wall mount.
3. Center the scale side to side (between the rubber bumpers) in the channel of the wall mount.
Wall
Mount
Rubber
Bumper
Rubber
To Next Page
