0065-0647-OM Rev E 7550 OWNER’S MANUAL
SPECIFICATIONS
Capacity: 1,000 lb x 0.2 lb / 450 kg x 0.1 kg
Platform Size (Flat Portion): 36.0 in W x 33.0 in D / 91.4 cm W x 83.8 cm D
Overall Dimensions
Width:
Depth:
Height:
50.3 in / 127.6 cm
39.3 in / 99.7 cm (with platform extended)
7.3 in / 18.4 cm (without platform extended)
44.0 in / 111.7 cm
Display Type: 3.2 in (diagonal) full color TFT display
320 x 240 resolution
Number of Characters: Weight: 5 digits, 0.8 in (20 mm) high
Height: 4 digits, 0.35 in (9 mm) high
BMI: 3 digits, 0.35 in (9 mm) high
Touch Screen: Resistive touch panel covering the display
Keys: Mechanical switch type, Power, Zero, Lock/Release, ID,
Cycle Display Mode, Menu, Print
Power Requirements: Six C-size Alkaline, Ni-Cad, or NiMH batteries (not included)
Domestic models: Optional 100 to 240V AC 50/60Hz 12V
DC 1A wall plug-in UL/CSA listed AC power adapter
(Cardinal part number 6800-1045)
International models: Optional 100 to 240V AC 50/60Hz 12V
DC 1A Multi-Pin Input AC power adapter (Cardinal part
number 6800-1047)
Operating Environment: Operated Temperature Range: 14 to 104 ºF (-10 to +40 ºC)
Humidity: 0 to 90% non-condensing
Communication Interfaces: Wi-Fi and Bluetooth 5.0
Weight: 180 lb
Standard Features:
Slim 7.3 in / 18.5 cm Profile Units Locking into LB or KG
2-Way Easy Access Ramps Auto Weight Lock Feature
Compact Vertical Fold-Up Platform 8-Digit Numeric Patient ID
Gas Spring Lifting Mechanism StableSENSE
® 1
Adjustable Filtering
Sturdy Steel Construction Wi-Fi and Bluetooth 5.0
1
StableSENSE
®
is a digital filter utilizing proprietary software algorithms to remove or greatly
reduce changes in the weight display resulting from movement on the scale platform.
StableSENSE
®
can be used with clinical scales to lessen the effects of the patient’s
movement or vibration on the scale. Any application affected by vibration or movement on
the scale platform can benefit from using StableSENSE
®
.
