0065-0647-OM Rev E 7550 OWNER’S MANUAL
WI-FI SETUP, CONT.
Changing the Network Credentials
1. With the scale turned on and the Weight screen displayed, press the Menu key.
2. The display will change to show the Settings Overview 1 screen.
3. Press Setup on the touchscreen.
4. The display will change to show the ENTER PASSCODE screen.
5. Using the 10-key on the touchscreen, enter 64870 and then press Save.
6. The display will change to show the Settings Page 1 screen.
7. Press >>> to advance to the Settings Page 7 screen.
8. Touch SSID: on the touchscreen.
9. You will be prompted to clear the network credentials.
CLEAR SSID
0
1= Clear
wireless
profile
1 2 3
4 5 6
7 8 9
SAVE CANCEL
0 .
DEL
10. Press 1 on the entry screen, and then press Save to clear the credentials.
11. Press Exit to exit Setup, and return to the Weight screen.
12. Repeat the steps in the Configure Wi-Fi Network Module on the previous page to set the
new network credentials.
Display the Wi-Fi Network Settings
1. With the scale turned on and the Weight screen displayed, press the Menu key.
2. The display will change to show the Settings Overview 1 screen.
3. Press >>> to advance to the Settings Overview 2 screen.
4. The scale’s Wi-Fi network settings will be shown.
5. Press Exit to exit Settings Overview 2 and return to the Weight screen.
You should see the status of the Wi-Fi on the Settings Overview 2 screen. If a scan of Wi-Fi
networks shows the “REDBIRD_WIFI_XX:XX” AP, then the module is in listening mode. Refer
to the Configure Wi-Fi Network Module section for the procedure to set the Wi-Fi credentials.
