0065-0647-OM Rev E 7550 OWNER’S MANUAL
KEYPAD FUNCTIONS
DO NOT operate the keys or touchscreen with pointed objects (pencils, pens,
etc..). Damage to keys or touchscreen resulting from this practice is NOT
covered under warranty.
This is the Power key. With the scale off, pressing this key will apply power to
the scale and turn on the display. If the scale is already on, pressing this key
will turn it off.
This is the Zero key. Press and release this key to reset the display to zero.
Note that when this key is pressed with weight on the scale platform, the
display will zero the weight up to 100% of the scale capacity, and the display
will change to zero (0.0). When the weight is removed, the display will show a
negative weight. Press the 0 key again to reset the display to zero (0.0).
This is the Lock/Release key. Press and release this key, or touch the weight
readout on the display to cause the weight, height, and BMI to lock on the
current values until the key is pressed again or the weight readout on the
display is touched again. While the weight is locked, the weight status will
change to LOCKED to denote that the weight is being held.
This is the ID key. Press and release this key to open the ID entry screen, and
then using the touchscreen, enter a numeric ID. Note that the ID is NOT used
for tracking patient measurements, it is only transmitted out of the selected
communication port when the key is pressed. To change or edit the ID,
simply press the ID key again to return to the ID entry screen.
This is the Display Mode key. Press and release this key to cause the display
to cycle between display modes: Weight/Height/BMI or Weight only.
