Issue: June 2005 Section C –Assembly Instructions Page C.1
SECTION C - ASSEMBLY INSTRUCTIONS
The following pages give the assembly instructions and techniques for the HI280 shelving
components and accessories.
Each page deals with a separate component or aspect of the build.
Where appropriate reference should be made to the separate schedule pages for the number of
components required and their positioning, i.e. ‘Frame Assembly’ and ‘Back Cladding’ schedules.
The frame assembly pages describe the overall method assembly recommending the use of
assembly jigs. These jigs are explained in more detail within the previous section of this document
together with useful tips.
Larger more complex installations such as multi-tiers and high rise structures will require additional
components such as flooring, stairways, safety railing etc.
These specialist components will be specific to the installation and will be detailed separately.
