ASSEMBLY INSTRUCTIONS – FIXING DOWN A RACK
Note: All racks that are fitted with either drawer or tray sets MUST be fixed to the floor.
Racks that have a height to the top loaded shelf greater than 5 times the frame width
MUST be fixed to the floor.
Any baseplate that is fixed down MUST also be fixed to the upright.
A. Drill an 8mm diameter hole into the floor with sufficient depth to accept the fixing.
B. Place the fixing in the hole and drive the fixing into the sleeve with a hammer.
C. If the fixing needs to be removed at some later date, it can be simply removed by
unscrewing it with a screwdriver.
Issue: June 2005 Section C –Assembly Instructions Page C.12
