Issue: June 2005 Section E – Frame Assembly Schedule Page E.15
HIGH RISE - 4 HEAVY DUTY BATTENS (riveted) (continued).
Frame First Batten Batten Batten Top
Height Batten Centres Centres Centres Batten
‘H’ ‘A’ ‘B’ ‘C’ ‘D’ ‘E’
3100mm 211 600 900 900 489
3200mm 211 600 1000 900 489
3300mm 211 600 1000 1000 489
3400mm 211 700 1000 1000 489
3500mm 211 700 1000 1100 489
3600mm 211 700 1100 1100 489
3700mm 211 700 1100 1200 489
3800mm 211 800 1100 1200 489
3900mm 211 800 1100 1300 489
4000mm 211 800 1200 1300 489
4100mm 211 800 1300 1300 489
4200mm 211 900 1200 1400 489
4300mm 211 900 1300 1400 489
4400mm 211 900 1300 1500 489
4500mm 211 900 1400 1500 489
4600mm 211 1000 1300 1600 489
4700mm 211 1000 1400 1600 489
4800mm 211 1000 1400 1700 489
4900mm 211 1000 1500 1700 489
5000mm 211 1100 1500 1700 489
5100mm 211 1100 1500 1800 489
5200mm 211 1100 1600 1800 489
5300mm 211 1100 1600 1900 489
5400mm 211 1200 1600 1900 489
5500mm 211 1200 1600 2000 489
