Issue: June 2005 Section E – Frame Assembly Schedule Page E.39
FULLY SOLID CLAD FRAMES (continued).
Frame No. of No. of No. of Quantity of each cladding sheet type
height clad clad swage 900 1000 1600 2100 2300 2500
‘H’ sheets trim fixings mm mm mm mm mm mm
10000mm 4 3 56 4
10100mm 5 4 62 1 4
10200mm 5 4 64 1 4
10300mm 5 4 62 1 3 1
10400mm 5 4 62 1 2 2
10500mm 5 4 60 5
10600mm 5 4 64 1 1 3
10700mm 5 4 62 4 1
10800mm 5 4 66 1 4
10900mm 5 4 62 1 4
11000mm 5 4 64 1 4
11100mm 5 4 66 2 3
11200mm 5 4 64 1 1 3
11300mm 5 4 68 1 4
11400mm 5 4 66 1 1 3
11500mm 5 4 70 5
11600mm 5 4 66 1 4
11700mm 5 4 70 4 1
11800mm 6 5 70 2 3 1
11900mm 5 4 70 3 2
12000mm 6 5 72 2 2 2
