Issue: June 2005 Section F – Full Width Back Cladding Schedule Page F.3
FULL WIDTH BACK CLADDING SCHEDULE (continued)
Rack No. of No. of No. of Quantity of each cladding sheet type
height cladding cladding cladding 800 1000 1200 1300
‘H’ sheets trims clips mm mm mm mm
6000mm 5 4 30 5
6100mm 5 4 30 4 1
6200mm 5 4 30 3 2
6300mm 5 4 30 2 3
6400mm 5 4 30 1 4
6500mm 5 4 30 5
6600mm 6 5 36 3 3
6700mm 6 5 36 3 2 1
6800mm 6 5 36 2 4
6900mm 6 5 36 2 3 1
7000mm 6 5 36 1 5
7100mm 6 5 36 1 4 1
7200mm 6 5 36 6
7300mm 6 5 36 5 1
7400mm 6 5 36 4 2
7500mm 6 5 36 3 3
7600mm 6 5 36 2 4
7700mm 6 5 36 1 5
7800mm 6 5 36 6
7900mm 7 6 42 3 3 1
8000mm 7 6 42 2 5
8100mm 7 6 42 2 4 1
8200mm 7 6 42 1 6
8300mm 7 6 42 1 5 1
8400mm 7 6 42 7
8500mm 7 6 42 6 1
8600mm 7 6 42 5 2
8700mm 7 6 42 4 3
8800mm 7 6 42 3 4
8900mm 7 6 42 2 5
9000mm 7 6 42 1 6
9100mm 7 6 42 7
9200mm 8 7 48 2 6
9300mm 8 7 48 2 5 1
9400mm 8 7 48 1 7
9500mm 8 7 48 1 6 1
9600mm 8 7 48 8
9700mm 8 7 48 7 1
9800mm 8 7 48 6 2
9900mm 8 7 48 5 3
