Chapter 2 Hardware Installation
Chapter 2
Installing the SDVO-LVDS Daughterboard onto
the Motherboard (optional)
1. Thephotobelowshowsthelocationofthemountingholeonthemotherboard.
Mountinghole
2. Inserttheprovidedmountingscrewintothemountinghole-fromthebottomthroughthe
topofthemotherboard.
Mountingscrew
LCD/Inverter Power Connector
Pins Function
1
GND
2
GND
3
PanelInverterBrightnessVoltageControl
4
PanelPower
5
+3.3V
6
PanelBacklightOn/OffControl
7
+12V
8
+12V
Important:
Themotherboardusedinthissectionisforreferencepurposeonlyandmaynot
resembleyourmotherboard.Theseillustrationsaremainlytoguideyouonhowto
installSDVO-LVDSontothemotherboardofyourchoice.
Mountinghole
