Chapter 3 BIOS Setup
Chapter 3
South Bridge
PCI Express Coniguration
settings.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Intel PCH RC Version
Intel PCH SKU Name
Intel PCH Rev ID

PCI Express Confi guration

USB Confi guration
Onboard 82579 LAN Controller
Wake on LAN
High Precision Event Timer Confi guration
High Precision Timer
After G3
1.5.0.0
H61
05/B3
[Enabled]
[Enabled]
[Enabled]
[Power on]
Chipset
 Select Screen
 Select Item
Enter: Select
+/
-:
Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
ESC: Exit
Onboard LAN 82579 LAN Controller
Enabled or disable LAN.
Wake on LAN
Enable or disable integrated LAN to wake the system. (The Wake on LAN cannot be
disabled if ME is on at Sx state.)
High Precision Timer
Enable or disable the High Precision Timer.
After G3
Power Off / WOL
Power-on the system via WOL after G3.
Power On
Power-on the system after G3.
Control the PCI Express
Root Port
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
PCI Express Confi guration
PCI Express Root Port
Onboard 82574 LAN Controller
[Enabled]
[Enabled]
Chipset
 Select Screen
 Select Item
Enter: Select
+/
-:
Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
ESC: Exit
PCI Express Configuration
Onboard 82574 LAN Controller
Enables or disables onboard 82574 LAN controller.
