Maintenance Manual LS8
Issued: December 2009
Copyright DG Flugzeugbau GmbH - any copy or publishing prohibited
Manual valid with the up-to-date cover page only
11.2
11.2 Repairs of Metal Fittings
Repairs of Metal Fittings should not be performed before the manufacturer
has been consulted. Most fittings are made from 1.7734.4 aircraft material
and welded in 141-WIG process (Shielded arc welding). In no case should
they be gas welded, because required properties of the material will
disappear.
11.3 Control cables and connections
For processing Nicopress sleeves refer to FAA "Aircraft Inspection and
Repair” FAA AC 43.13-1 A or later issue
1. Rudder cables
Cable: B 3.2 MIL-W-83420 I/A resp. ISO 2020 (former LN9374) zinc
plated
Steel thimbles: A 3.5 DIN6899
Cable sleeves: Nicopress NT 283M (28-3-M)
, 3 pressings required, with
tool groove Oval M tool 64-CGMP
2. Tow hook operation and wheel brake
Cable: A 2.4 MIL-W-83420 I/A resp. ISO 2020 (former LN9374)
A 2.4 LN9389 corrosion resistant (C.G. hook)
2.5 DIN3055 corrosion resistant with steel core (C.G. hook)
Steel thimbles: A 2.5 DIN6899
Cable sleeves: Nicopress NT 282GA (28-2-G)
, for pressing use tool groove Oval
G of tool 64-CGMP. 1 press (
Stop sleeve: Nicopress NT S117J (871-17-J), use tool groove "J" of tool
51-MJ 1-press
3. Waterballast control
Cable: 1.2 LN9389 (stainless) resp. 1,25mm D construction 7x7
DIN3055 stainless steel 1.4401
Steel thimble: A 1.7 DIN 6899
connected with screw nipple 4F5-120
Stop sleeve: Nicopress NT S117J (871-17-J), for pressing use
a. groove "J"
of tool 51-MJ, thereafter
b. groove "G"
of tool 64-CGMP, 1 press each in
given sequence
