DG Flugzeugbau LS8 - Limit Values for Control Surface Deflections

Maintenance Manual LS8
Issued: June 2016 TN8024
Copyright DG Flugzeugbau GmbH - any copy or publishing prohibited
Manual valid with the up-to-date cover page only
5-6
5.5 Limit values for control surface deflections
Deflections in mm / in
Ailerons:
LS8
local radius 16° to 17° 21° to 22°
down up
mm in mm in mm in
120 4.724 33 to 35 1.299 to 1.378 44 to 46 1.732 to 1.811
121 4.764 34 to 36 1.339 to 1.417 44 to 46 1.732 to 1.811
122 4.803 34 to 36 1.339 to 1.417 44 to 47 1.732 to 1.850
123 4.843 34 to 36 1.339 to 1.417 45 to 47 1.772 to 1.850
124 4.882 35 to 37 1.378 to 1.457 45 to 47 1.772 to 1.850
125 4.921 35 to 37 1.378 to 1.457 46 to 48 1.811 to 1.890
126 4.961 35 to 37 1.378 to 1.457 46 to 48 1.811 to 1.890
127 5.000 35 to 38 1.378 to 1.496 46 to 48 1.811 to 1.890
128 5.039 36 to 38 1.417 to 1.496 47 to 49 1.850 to 1.929
129 5.079 36 to 38 1.417 to 1.496 47 to 49 1.850 to 1.929
130 5.118 36 to 38 1.417 to 1.496 47 to 50 1.850 to 1.969
LS8-a, LS8-b, LS8-18
local radius 13° to 15° 26° to 30°
down up
mm in mm in mm in
75 2.953 17 to 20 0.669 to 0.787 34 to 39 1.339 to 1.535
76 2.992 17 to 20 0.669 to 0.787 34 to 39 1.339 to 1.535
77 3.031 17 to 20 0.669 to 0.787 35 to 40 1.378 to 1.575
78 3.071 18 to 20 0.709 to 0.787 35 to 40 1.378 to 1.575
79 3.110 18 to 21 0.709 to 0.827 36 to 41 1.417 to 1.614
80 3.150 18 to 21 0.709 to 0.827 36 to 41 1.417 to 1.614
81 3.189 18 to 21 0.709 to 0.827 36 to 42 1.417 to 1.654
82 3.228 19 to 21 0.748 to 0.827 37 to 42 1.457 to 1.654
83 3.268 19 to 22 0.748 to 0.866 37 to 43 1.457 to 1.693
84 3.307 19 to 22 0.748 to 0.866 38 to 43 1.496 to 1.693
85 3.346 19 to 22 0.748 to 0.866 38 to 44 1.496 to 1.732
