Maintenance Manual LS8
Issued: June 2016 TN8024
Copyright DG Flugzeugbau GmbH - any copy or publishing prohibited
Manual valid with the up-to-date cover page only
5-7
Elevator
LS8
local radius 22°to 24° 28°to 30°
down up
mm in mm in mm in
67 2.638 26 to 28 1.024 to 1.102 32 to 35 1.260 to 1.378
68 2.677 26 to 28 1.024 to 1.102 33 to 35 1.299 to 1.378
69 2.717 26 to 29 1.024 to 1.142 33 to 36 1.299 to 1.417
70 2.756 27 to 29 1.063 to 1.142 34 to 36 1.339 to 1.417
71 2.795 27 to 30 1.063 to 1.181 34 to 37 1.339 to 1.457
72 2.835 27 to 30 1.063 to 1.181 35 to 37 1.378 to 1.457
LS8-a, LS8-b, LS8-18
local radius 22°to 26° 28°to 30°
down up
mm in mm in mm in
67 2.638 26 to 30 1.024 to 1.181 32 to 35 1.260 to 1.378
68 2.677 26 to 31 1.024 to 1.220 33 to 35 1.299 to 1.378
69 2.717 26 to 31 1.024 to 1.220 33 to 36 1.299 to 1.417
70 2.756 27 to 31 1.063 to 1.220 34 to 36 1.339 to 1.417
71 2.795 27 to 32 1.063 to 1.260 34 to 37 1.339 to 1.457
72 2.835 27 to 32 1.063 to 1.260 35 to 37 1.378 to 1.457
Rudder all LS8
Measured value = Distance from trailing edge to centre of cable bolt
measured value local radius 26°to 30°
mm in mm in mm in
395 15.551 390 15.354 175 to 202 6.890 to 7.953
396 15.591 391 15.394 176 to 202 6.929 to 7.953
397 15.630 392 15.433 176 to 203 6.929 to 7.992
398 15.669 393 15.472 177 to 203 6.969 to 7.992
399 15.709 394 15.512 177 to 204 6.969 to 8.031
400 15.748 395 15.551 178 to 204 7.008 to 8.031
