Maintenance Manual LS8
Issued: December 2009
Copyright DG Flugzeugbau GmbH - any copy or publishing prohibited
Manual valid with the up-to-date cover page only
1-7
1.4 Elevator control system
The mass of the elevator pushrod in the vertical tail fin is adapted to elevator
mass.
See mass value entered in inspection form "Control Surface mass and Moment"
for this serial number
No
Designation Drawing
1 Trim locking lever 4R9-24
2 Control stick 3R3-49
3 Control stick
support
1R3-65
4 Trim lever 4R9-95
5 Trim bowden cable
6 Trim rod 4R9-76
7 Trim locking
housing
3R9-74
8 Rear trim spring
9 Vertical tail fin
elevator pushrod
4R3-79
10 Rear horizontal tail
bracket
4R4-6
11 Rear tapered bolts 4R4-4
12 Securing nut 4R4-8
13 Elevator connector
bracket
4R3-62
14 Automatic
connector
3R3-63
15 Elevator lever 4R3-7
16 Elevator lever
bracket
4R3-40
17 Forward trim spring
18 Forward elevator
pushrod
4R3-84
19 Elevator pushrod 2 4R3-85
20 Elevator pushrod 3 4R3-76
21 Rear elevator
pushrod
4R3-69
