9 Instruments- and Equipment List (Master Equipment List)
Maximum mass of all Instrument Panel Installations max. 6.7 kg <14.8 lbs>.
9.1 Airspeed Indicator
Manufacturer Type TCDS No.
W
inte
r
6FMS-4 (Diameter 80mm)
0-300 km/h Ident.No.. LS-8-2
0-160 kts Ident.No.. LS-8K-2
6FMS-5 in km/h
TS 10.210/15
W
inte
r
7FMS-4 (Diameter 58mm)
0-300 km/h Ident.No.. LS-8-2
0-160 kts Ident.No.. LS-8K-2
TS 10.210/19
Thommen 5A58() range 300 km/h
P
ZL PR-400 S-A in km/h
or other Airspeed indicators approved according to TSO, JTSO or ETSO for
use in aircraft or similar FAA approved airspeed indicators to meet TSO C2
reading to 300 km/h <160 Kt., 180 mph> may be used. Maximum instrument
error ±2%. Colour marking must be according to Flight Manual section 2-3.
9.2 Altimeter
Manufacturer Type TCDS No.
Winter 4 FGH 10 (Diameter 80mm)
1000-10000m Ident.No.. 4110
3000-30000ft Ident.No.. 4330
TS 10.220/46
Winter 4 FGH 20 (Diameter 58mm)
1000-10000m Ident.No. 4220
TS 10.220/47
Winter 4 FGH 40 (Diameter 58mm)
1000-20000ft Ident.No.. 4550
TS 10.220/48
PZL W-12S in m
or other Altimeters approved according to TSO, JTSO or ETSO for use in
aircraft; one turn of dial max. 1000 m or 3000 ft. A similar FAA approved
altimeter to meet TSO C10 with a range of approximately 33000 ft and a
mercury or millibar or hektopascal subscale may be used. When an altimeter
of up to 20000 ft only is being used, a placard must be near the altimeter
stating: Maximum flying altitude 20000 ft. See also Flight Manual section
2-8.
