Maintenance Manual LS8
Issued: June 2016 TN 8024
Copyright DG Flugzeugbau GmbH - any copy or publishing prohibited
Manual valid with the up-to-date cover page only
2-5
Calculation of loading limits
continued
Example for entry in Flight Manual, section 6.2:
Wing span [m] 15 18
Empty mass [kg / lbs]
265/584 275/606
C.G. position [mm / in]
659/25.9
Max. Cockpit
Load
[kg / lbs]
104/229
Tail tank full [kg / lbs]
110/243
With tail
battery
Tail tank
empty (+)
[kg / lbs]
100/220
Tail tank full [kg / lbs]
80/176
Minimum
Cock
it Load
Without
tail
battery
Tail tank
empty (+)
[kg / lbs]
70/154
front [kg / lbs]
--
Fixed
trim
ballast
rear [kg / lbs]
--
Seat front end [number]
1
Baggage
Comp.
[number]
0
Batterie
s
installed
Vertical tail
fin
[number]
1
Date / Inspector
18.3.2002 GS
Warning: The discrepancy between Maximum Cockpit Load of 104 kg <229 lbs>
and Minimum Cockpit Load of 110 kg <242 lbs> with tail fin tank full indicates,
that before each take off the installation position of the tail fin battery must be
checked and functional check for the tail fin tank valve is required to make sure
that no unintended amount of water remains in the fin tank..
To check the valve place tail tank filling adapter into the tank outlet and open the
cockpit lever. If air cannot be blown into the tank, the valve is not functioning
properly (for instance frozen solid or operating cable fractured)
