Maintenance Manual LS8
Issued: December 2009
Copyright DG Flugzeugbau GmbH - any copy or publishing prohibited
Manual valid with the up-to-date cover page only
4-15
Sketch 2
LS8-a und LS8-18 with slide in tail fin tank
A -to cockpit lever
B - to tail tank
C - right side fuselage drive
D -to left fuselage drive
E - right wing drive lever
F - inner wing tank valve,
may be produced without
the slot
G -rib between both tanks
H -outer wing tank valve
inner dump
valve
outer dump
valve
