SM-200 TE Grinding and Honing Machine
20
Design and Function
6
Cooling water unit
Emissions sound pressure level
Sound emission in accordance with EN ISO 11201.
Ambient conditions
Volume of cooling water circulated: 40 I/min
Content of water tank 20 litres
Pump
Power 0.12 kW
Degree of protection IP54
Connection 3~400 V (three-phase)
A-rated emissions sound pressure level at the work
area measured at idling speed L
pA
:73dB (A)
Uncertainty K
pA
; uncertainty in decibels: 3 dB (A)
A-rated emissions sound pressure level at the work
area measured when grinding a hand knife L
pA
:77dB (A)
Uncertainty K
pA
; uncertainty in decibels: 3 dB (A)
Temperature
Storage: 3 - 40 °C
Operation: 3 - 30 °C
Usage: indoors
