SM-200 TE Grinding and Honing Machine 49
Machining Workpieces
9
The knife can now be ground.
Remove the machine knife from the grinding plate
1 Place the double grinding arm in the grinding lever support
again to remove the machine knife.
2 Open the clamping device of the grinding plate and remove
the knife.
9.3 Sharpening knives
The machine knife is clamped in the grinding plate on the double
grinding arm.
1 Adjust the grinding angle on the grinding device.
2 Lift the workpiece off the grinding wheel with the double grind-
ing arm.
3 Set the On/Off switch for the abrasives to position I (ON).
4 Set the On/Off switch for the cooling water to position I (ON).
5 Lower the workpiece with the double grinding arm. Move the
area to be ground back and forth over the grinding wheel with
light pressure.
6 Move the workpiece back and forth with the double grinding
lever.
7 Repeatedly raise the workpiece and check the progress of the
grinding.
8 Complete the process when a burr has formed on the cutting
edge.
NOTE
Do not stop the movement of the workpiece on the grinding
wheel.
• There is a risk that the knife will overheat and the contour will
be damaged if the workpiece remains stationary on the grin-
ding wheel.
NOTE
Follow the instructions of the knife manufacturer for grinding work-
pieces.
