5.5 Signage
Figure 5.2 – Position of the signs
[9] Type plate on the cooling water tank
[10] Functional description of the foot pedal
Note:
Arrow on the machine housing for the correct
direction of rotation for the abrasives
Mandatory sign:
Use safety goggles
Mandatory sign:
Pull out the mains plug before opening.
Note:
Moving parts under the cover.
Warning sign:
Caution: high voltage
Note:
Direction of rotation to loosen the grinding belt.
Note:
Function of the foot pedal.
9
10
