Safety
5
5.4 ::Signs on the grinding and honing machine
Figure 5.1 – Position of the signs
[1] Wear hearing protection and safety goggles when working
with the SM-200 TE grinding and honing machine.
[2] Direction of rotation on the grinding belt and polishing station
[3] Functional description for switches
[4] Note - moving parts under the cover.
[5] Direction of rotation for loosening the grinding belt.
[6] Disconnect the mains plug before opening the cover.
[7] Type plate
[8] Caution: electric shock - parts under the cover may be live.
1
2
3
1
4
5
6
7
8
