Dick SM-200 TE - 6 Design and Function; Technical Data

SM-200 TE Grinding and Honing Machine 19
Design and Function
6
6. Design and Function
6.1 Technical data
Motor and electrics
Grinding wheel
Grinding belt
Polishing wheel
Machine dimensions / weights
Power: 1.3 kW
Voltage: 3~400 V (three-phase)
Current intensity: 4.13 A
Frequency: 50/60 Hz
Type of operation: S3-70%
Degree of protection: IP 54
Connection: 3.5 m cable H05VV-F5G1.5 incl. 5-
pin CEE plug 16 A
Nominal speed: 2800 1/min (50 Hz)
Art. no.: 9 4601 010
Dimensions: Ø 200 x 60 mm
Rpm: 384 1/min (50 Hz)
Cutting speed: V
c
= 4.0 m/s (50 Hz)
Art. no.: 9 4601 120
Dimensions: 1250 x 60 mm - P120
Rpm (spindle): 1440 1/min (50 Hz)
Cutting speed: V
c
= 15.1 m/s (50 Hz)
Art. no.: 9 4601 180
Dimensions: Ø 200 x 50 mm
Rpm: 1440 1/min (50 Hz)
Cutting speed: V
c
= 15.1 m/s (50 Hz)
Depth: 830 mm
Width: 650 mm
Height: 500 mm (without a stand)
Weight: 98 kg (without a stand)
