SM-200 TE Grinding and Honing Machine 37
Setting up the Machine
8
8.5 Setting the guard ring
The guard ring prevents the user having any contact with the grind-
ing wheel and stops water splashing.
The grinding wheel is subject to wear. The guard ring must not
impede the grinding process.
1 Set the On/Off switch for the abrasives to position 0 (OFF).
2 Wait until the grinding wheel stops rotating.
3 Hold the guard ring with the hand.
4 Loosen the star handle. Place the guard ring in the correct
position. The grinding wheel must protrude 2 mm above the
guard ring.
5 Tighten the star handle.
8.6 Setting the universal grinding arm
The universal grinding arm provides a wide range of settings for
grinding different round and straight cutting edge shapes.
Knives with a straight cutting edge
The rotary function of the universal grinding arm is blocked and the
sliding function is released for grinding a knife with a linear
(straight) cutting edge.
Figure 8.4 – Adjusting the guard ring
[1] Guard ring
[2] Star handle
