Figure 9.2 – Grinding a knife
[1] Knife positioned at a right angle to the wet grinding belt
[2] Knife edge
[3] Direction of rotation of the wet grinding belt
Figure 9.2 – Grinding a knife
[4] Knife blade
[5] Positioning angle for the knife blade (15°) and cleaver (20°).
1
3
2
5
4
