003 Family Setup Guide2
• One MIDI In port and two MIDI Out ports,
providing up to 16 channels of MIDI input
and up to 32 channels of MIDI output.
003 Rack+
• Eight analog audio inputs.
• Each input channel features:
• Support for microphone (XLR) and Line/DI
(1/4” TRS) inputs.
• 75 Hz high-pass filter (HPF), switchable per
channel.
• 48V phantom power on mic inputs, swit-
chable per channel.
• –20 dB pad, switchable per channel.
• Front panel DI input.
• One MIDI In port and one MIDI Out port,
providing up to 16 channels of MIDI input
and up to 16 channels of MIDI output.
Control Surface Features
(003 Only)
003 provides an integrated control surface that
includes the following:
• Eight motorized touch-sensitive faders for
controlling track volume and other parame-
ters. Includes ability to disable faders during
playback of automated mixes.
• Dedicated Solo, Mute and Channel Se-
lect/Record Arm switches.
• Eight multifunction rotary encoders for oper-
ating pan, send, and plug-in controls.
• Fast and convenient access to sends, inserts,
plug-in pages, pan settings, and other track
functions.
• Automation Mode switches for selecting and
displaying Automation modes.
• Large, bright LCD for data display.
• Transport controls, plus Transport mode
switches for loop playback, loop record, and
QuickPunch.
• Dual-concentric Jog/Shuttle wheel.
• Save, Undo, and Enter switches. Memory Lo-
cation switch for recalling Memory Locations
or opening the Memory Location window.
• Windows switches for Pro Tools display of
plug-in, Mix, and Edit windows.
• Navigation and Zoom controls.
• MIDI mode switches for MIDI mapping.
• Utility mode switch for testing 003.
Pro Tools LE Capabilities
Pro Tools LE
™
on Mac or Windows provides the
following capabilities with Mbox 2 Pro:
• Playback of up to 48 mono or stereo digital
audio tracks, or a combination of playing
back and recording up to 48 mono or stereo
digital audio tracks, depending on your
computer’s capabilities.
• Up to 128 audio tracks (with up to 48 active
tracks), 128 Auxiliary Input tracks, 64 Mas-
ter Fader tracks, 256 MIDI tracks, and 32 In-
strument tracks per session.
• 16-bit or 24-bit audio resolution, at sample
rates up to 48 kHz.
• Non-destructive, random-access editing
and mix automation.
• Audio processing with up to 10 inserts per
track (RTAS plug-ins or hardware inserts).
• Up to 10 sends per track.
• Up to 32 internal mix busses.
