003 & 003 Rack Getting Started Guide118
Routing Path for Audio Tests
:
Testing Audio Connections
To test audio connections:
1 Make the necessary connection for the input
and output you are testing. See “Routing Path
for Audio Tests” on page 118.
2 Enter Utility mode. If the Utility switch is not
enabled (flashing), press it.
3 Select the Test menu by pressing the flashing
Insert switch.
The LCD shows the first page of Utility tests.
4 Press the ESC switch to toggle to the second
page of Utility tests.
5 Enter “Audio” test mode by pressing the flash-
ing Inserts (Channel View) switch.
6 Begin an Audio test by pressing the Channel
View switch that corresponds to the test you
want to run.
7 For the S/PDIF In and Out tests, press the Dy-
namics or Insert switch repeated times to toggle
through the different test, or to test all of the
S/PDIF routing paths.
8 When finished, press the flashing Display
switch.
Audio Test Routing Path
Intl Internal loopback of all analog and
digital I/O channels (Analog Input 1
to Analog Output 1, Analog Input 2
to Analog Output 2, and so on).
Sgnl 003 generates a 440 Hz sine wave
on all analog and digital outputs.
Level is adjustable from 0 dB to
–42 dB with the rotary encoder in
the second fader strip.
SpIn 1/2 S/PDIF (RCA) Inputs to Analog
Outputs 1–2.
SpIn 3/4 S/PDIF (RCA) Inputs to Analog
Outputs 3–4.
SpIn 5/6 S/PDIF (RCA) Inputs to Analog
Outputs 5–6.
SpIn 7/8 S/PDIF (RCA) Inputs to Analog
Outputs 7–8.
SpIn All S/PDIF (RCA) Inputs to all Analog
Output pairs.
SpOt 1/2 Analog Inputs 1–2 to S/PDIF (RCA)
Outputs.
SpOt 3/4 Analog Inputs 3–4 to S/PDIF (RCA)
Outputs.
SpOt 5/6 Analog Inputs 5–6 to S/PDIF (RCA)
Outputs.
SpOt 7/8 Analog Inputs 7–8 to S/PDIF (RCA)
Outputs.
SpOt All All Analog input pairs to S/PDIF
(RCA) Outputs.
SpAg Simultaneous routing of S/PDIF
(RCA) Inputs to Analog Outputs 1–2
and Analog Inputs 1–2 to S/PDIF
(RCA) Outputs.
Adat Simultaneous routing of ADAT
Optical Inputs to Analog Outputs
1–8 and Analog Inputs 1–8 to ADAT
Optical Outputs.
