Chapter 1: Introduction to D-Control 5
Mechanical Specifications
D-Control Stand Dimensions (not including video display arm)
Maximum Height 39.7 inches (100.9 cm)
Maximum Width
Main Unit with 1 Fader Module (16-channel system) 65.3 inches (165.9 cm)
Main Unit with 2 Fader Modules (32-channel system) 88.5 inches (224.8 cm)
Maximum Depth 45.7 inches (116.1 cm)
Figure 1. Stand dimensions for a 16-fader D-Control system
Figure 2. Stand dimensions for a 32-fader D-Control system
