DG-BG4100NU User Manual
125
6 Appendix
6.1 Technical Specifications
Flash: 2MB
SDRAM: 16MB
Antenna: One fixed dipole 5dBi antenna
Network Interface: 1 x RJ11 interface for ADSL Line
4 x 10/100 Mbps UTP LAN ports
Wireless Features Standard: IEEE802.11b/g/n
Frequency band: 2.400~2.4835GHz
Wireless output power: 11B: 20±1.5dBm
11G: 18±1.5dBm
11N: 17±1.5dBm
Wireless security: WEP (64/128 bit), WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES),
WPA/WPA2 Mixed Mode, WPS (PBC/PIN Mechanism), Disable SSID
broadcast
Wireless data rate: 802.11b: 1/2/5.5/11Mbps
802.11g: 6/9/12/24/36/48/54Mbps
802.11n (20MHz): up to 72 Mbps
802.11n (40MHz): up to 150 Mbps
Status LEDs: Power
WLAN
ADSL
USB
