DG-BG4100NU User Manual
43
4.4.1.4 ATM Settings
Click ATM Settings in the left pane, the page shown in the f ollowing f igure appears. In this
page, you can configure the parameters of the ATM, including VPI, VCI, QoS, PCR, CDVT,
SCR and MBS.
The following table describes the parameters of this page:
The virtual path identif ier of the ATM PVC.
The virtual channel identif ier of the ATM PVC.
The QoS category of the PVC. You can choose UBR, CBR,
rt-VBR or nrt-VBR.
Peak cell rate (PCR) is the maximum rate at which cells can
be transmitted along a connection in the ATM network. Its
value ranges f rom 1 to 65535.
Cell delay v ariation tolerance (CDVT) is the amount of delay
permitted between ATM cells (in microseconds). Its value
ranges from 0 to 4294967295.
Sustained cell rate (SCR) is the maximum rate that traffic can
