DG-BG4100NU User Manual
46
The following table describes the parameters of this page:
Enter the IP address of LAN interf ace. It is recommended to use
an address from a block that is reserv ed f or priv ate use. This
address block for example is 192.168.1.1 - 192.168.1.254.
Enter the subnet mask of LAN interface. The range of subnet
mask is f rom 255.255.0.0 - 255.255.255.254.
Select it to enable the secondary LAN IP address. The two LAN
IP addresses must be in different networks.
When IGMP snooping is enabled, only hosts that belong to the
group receive the multicast packets. If a host is deleted from the
group, the host cannot receiv e the multicast packets any more.
It is the access control based on MAC address. Select it, and the
host whose MAC address is listed in the Current Allowed MAC
Address table can access the router.
Enter MAC address and then click it to add a new MAC address.
Current allowed
MAC address table
All the allowed MAC addresses added will be listed here.
