DG-BG4100NU User Manual
81
Mask
Source Port
The port of the source data packet.
Destination
Port
The port of the destination data packet.
Protocol
The protocol responds to the IP QoS rules. You can choose TCP,
UDP, or ICMP.
Phy Port
The LAN interf ace responds to the IP QoS rules.
IPP/DS Field
Select the IP packet header f ield ty pe, Select IPP/TOS (IP
Precedence/Ty pe of Service) f or defining the IPP Range or Select
DSCP (Differentiated Serv ices Code Point) for def ining the DSCP
Range.
IP Precedence
Range
Select the IP Precedence range values f or IPP/TOS.
Ty pe of service
Select the type of service.
DSCP Range
Ty pe the DSCP Value Range f rom 0~63.
Traffic Class
Range
Ty pe the Traff ic Class range f rom 0~255.
802.1p
You can choose from 0 to 7.
Priority
The priority of the IP QoS rules. P0 is the highest priority and P3 is
the lowest.
