The following table describes the parameters of this page:
Field
Description
Interf ace
Select the interf ace from the list.
Protocol
Select the below mentioned protocols from the list: None, ICMP, TCP,
UDP and TCP/UDP.
Src IP
The IP address of the source data packet.
Src Mask
The subnet mask of the source IP address.
Dst IP
The IP address of the destination data packet.
Dst Mask
The subnet mask of the destination IP address.
Src Port
The port of the source data packet.
Dst Port
The port of the destination data packet.
Up Floor
This value Should not be greater than Up Ceiling. This field def ines
Guaranteed Upload bandwidth.
Up Ceiling
This f ield def ines Maximum Upload bandwidth.
Down Floor
This v alue should not be greater than Down Ceiling. This field def ines
Guaranteed Download bandwidth.
Down Ceiling
This f ield def ines Maximum Download bandwidth.
