DG-BG4300NU User
Manual
113
The following table describes the parameters and buttons of this page:
Field Description
IP QoS Select to enable or disable IP QoS function. You need to enable IP
QoS if you want to configure the parameters of this page.
QoS Policy You can choose stream based, 802.1p based, or DSCP based.
Schedule Mode You can choose strict prior or WFQ (4:3:2:1).
Source IP The IP address of the source data packet.
Source Mask The subnet mask of the source IP address.
Destination IP The IP address of the destination data packet.
Destination Mask The subnet mask of the destination IP address.
Source Port The port of the source data packet.
Destination Port The port of the destination data packet.
Protocol The protocol responds to the IP QoS rules. You can choose T CP,
UDP, or IC MP.
Phy Port The LAN interface responds to the IP QoS rules.
Set priority The priority of the IP QoS rules. P0 is the highest priority and P3 is
the lowest.
802.1p You can choose from 0 to 7.
Delete Select a row in the QoS rule list and click it to delete the row.
Delete all Select all the rows in the QoS rule list and click it to delete the rows.
