DG-BG4300NU User
Manual
126
between March–April. Standard time begins in the
southern hemisphere between March–April and ends
between September–November. Many countries in the
southern hemisphere may observe DST.
NTP Configuration
State
Select enable or disable NTP function. You need to
enable NTP if you want to configure the parameters of
NT P.
Primary Server Set the primary NTP server manually.
Secondary Server Set the secondary NTP server manually.
Interval
Time when the NTP client will synchronise with NTP
server.
Time Zone
Choose the time zone in which area you are from the
drop down list.
4.8 Diagnostic
In the navigation bar, click Diagnostic. The Diagnostic page that is displayed contains Ping,
Traceroute, OAM Loopback, ADSL Statistics and Diag-Test.
4.8.1 Ping
Choose Diagnostic > Ping. The Ping page that is displayed contains Ping and Ping6.
4.8.1.1 Ping
Click Ping in the left pane, and the page shown in the following figure appears.
