DG-BG4300NU User
Manual
12
2 Hardware Installation
Step 1 Connect the ADSL interface of the device and the router interface of the splitter
through a telephone cable. Connect the phone to the Phone interface of the
splitter through a telephone cable. Connect the incoming line to the Line interface
of the splitter.
The splitter has three interfaces:
Line: Connect to a wall phone jack (RJ-11 jack).
Modem: Connect to the ADSL jack of the device.
Phone: Connect to a telephone set.
Step 2 Connect the LAN interface of the device to the network card of the PC through an
Ethernet cable (MDI/MDIX).
Note: Use twisted-pair cables to connect to the hub or switch.
Step 3 Plug one end of the power adapter to the wall outlet and the other end to the
Power interface of the device.
