DG-BG4300NU User
Manual
55
4.4.1.4 DHCP Static IP
Click DHCP Static IP in the left pane, the page shown in the following figure appears. You
can assign the IP addresses on the LAN to the specific individual PCs based on their MAC
address.
The following table describes the parameters and buttons of this page:
Field Description
IP Address Enter the specified IP address in the IP pool range,
which is assigned to the host.
MAC Address Enter the MAC address of a host on the LAN.
Add After entering the IP address and MAC address, click
it. A row will be added in the DHCP Static IP Table.
Delete Selected Select a row in the DHCP Static IP Table, then click it,
this row will be deleted.
Reset Click it to refresh this page.
DHCP Static IP Table It shows the assigned IP address based on the MAC
address.
